PHOTOBIO CX 2125 High Voltage 347-480V S4 + 10' Leads Cord

High-Voltage Compact Toplight with a 10' Leads Cord

The PHOTOBIO CX 2125 High Voltage 347-480V S4 is a compact, high-performance full-spectrum LED fixture built for industrial and commercial-grade facilities running 347-480V circuits.

Its 2.6" slim vertical design maximizes vertical growing space, while passive cooling fins and iLOC dimming give growers fine control over photon output as crops mature. This configuration includes a 10' leads (bare-wire) power cord for hardwiring to a 347-480V circuit.

Key Features & Benefits

• 347-480V High-Voltage Input — Driver auto-recognizes the facility's 347-480V circuit for industrial and commercial installs.
• S4 Full-Spectrum LED — Osram/Seoul diodes add red, far-red, and blue wavelengths to support vigorous growth and flower development.
• 2125 µmol/s Photon Flux @ 347V — 850W of LED output at 2.5 µmol/J efficacy.
• Secondary Optics — Improve light utilization and protect the diodes while directing more output toward the canopy.
• Slim Vertical Profile — 24.1L x 14.2W x 2.6H inches and 22.7 lbs, sized as a 1:1 footprint replacement for 1000W DE fixtures.
• iLOC Integrated Light Output Control — Push-button digital interface lets growers adjust photon output by crop stage; pairs with Autopilot PX2 and above controllers.
• Passive Cooling Fins — Dissipate heat without fans, keeping operating temperatures low.
• 10' Leads Power Cord Included — Bare-lead cord ships installed for hardwiring to a 347-480V circuit by a licensed electrician.
• 10' PHOTO•LOC 0-10V Control Cable — Connects to compatible dimming controllers and accessories.
• C-Clamps Included — Simplify mounting to standard horticultural light rail.
• DLC Hort Listed — Qualifies for utility rebate programs in eligible regions.
• IP66 Rated — Sealed against water and dust intrusion.
• 5-Year Warranty — Backed by the Hydrofarm team.

Who Should Use the PHOTOBIO CX 2125 High-Voltage Fixture

Commercial and industrial cultivators running 347-480V electrical infrastructure who want a slim 1:1 replacement for 1000W DE fixtures with onboard dimming control.

Electrical Installation Note

Consultation with a licensed electrician working alongside a qualified electrical engineer is recommended to confirm compliance with applicable electrical code and local inspection requirements before hardwiring the included leads cord.

Frequently Asked Questions

What facility voltage does this fixture require?

347-480V high-voltage input, auto-recognized by the driver.

Is this a direct replacement for 1000W DE fixtures?

Yes, it is built as a 1:1 footprint replacement while delivering higher photon flux and improved light distribution.

Can I dim this fixture?

Yes, through the onboard iLOC interface or by pairing with an Autopilot PX2 or higher controller.

What is the warranty?

5 years, backed by Hydrofarm.

What cord is included?

A 10' leads (bare-wire) power cord for direct hardwiring to a 347-480V circuit.

Is professional installation required?

We recommend consulting a licensed electrician for circuit sizing, receptacle selection, and code compliance.
