Anden Duct Kit, A210V1

Round Duct Kit for Anden Model A210V1 Dehumidifier – 12-Inch Collars

The Anden Model 5790 Round Duct Kit enables Anden A210V1 dehumidifiers to be installed outside the grow area and connected to the space via dedicated inlet and supply ductwork. This allows the dehumidifier's noise and heat output to remain outside the growing environment while still delivering its full dehumidification capacity into the grow space.

The 5790 kit includes galvanized steel transitions for both the inlet and the outlet of the A210V1. Collar diameter is 12 inches round, compatible with standard 12-inch round ductwork. The inlet transition includes a filter access door so that the A210V1's filter can be accessed and replaced even when the unit is installed in a ducted configuration outside the grow area.

Key Features & Benefits

• External Installation Capability — Enables the A210V1 to be installed outside the grow area and ducted in for reduced in-room noise and heat.
• 12-Inch Round Duct Collars — Collars sized for 12-inch round duct — compatible with standard HVAC ductwork.
• Galvanized Steel Construction — Durable galvanized steel transitions for long-term use in mechanical environments.
• Inlet and Outlet Transitions Included — Both inlet and outlet transitions provided in the kit.
• Filter Access Door on Inlet — Inlet transition includes a filter access door for filter replacement without removing ductwork.
• Reduces In-Room Noise — Locating the dehumidifier outside the grow room reduces operating noise within the growing environment.

Who Should Use This Kit

The Anden 5790 duct kit is for A210V1 installations where placing the dehumidifier inside the grow area is not practical — due to space constraints, noise sensitivity, or heat management requirements. Externally ducted dehumidifiers can significantly reduce the heat load and ambient noise within the grow space.

Ducted vs. In-Room Dehumidifier Installation

An in-room dehumidifier installation places the unit directly inside the growing space, where it processes air from the room and discharges both dry air and heat into the same space. A ducted installation moves the dehumidifier outside the room and connects it via ductwork, so the unit's heat output, noise, and maintenance needs stay outside the growing environment. The trade-off is that ducted installations require ductwork planning and a compatible duct kit such as the 5790.

Frequently Asked Questions

What dehumidifier model is this kit for?

The Anden 5790 Round Duct Kit is for the Anden Model A210V1 dehumidifier.

What duct size does it use?

The 5790 uses 12-inch round duct collars for both the inlet and outlet transitions.

Does the kit include both inlet and outlet transitions?

Yes. The 5790 includes galvanized steel transitions for both the inlet and outlet.

Can I access the filter when the unit is ducted?

Yes. The inlet transition includes a filter access door so the A210V1 filter can be accessed and replaced without removing ductwork.

What are the transition materials?

The inlet and outlet transitions are fabricated from galvanized steel.
